Contact data |
||||||||||
|
Contact Arrangement |
1A(1H) |
1B(1D) |
1C(1Z) |
|||||||
|
Contact Material |
Ag Alloys |
|||||||||
|
Conatct Rating(Resistive) |
10A 250VAC/28VDC |
10A 250VAC/28VDC |
NO:10A NC:10A |
|||||||
|
Max.Switching Power |
2500VA |
|||||||||
|
Max.Switching Voltage |
250VAC |
|||||||||
|
Max.Switching Current |
10 A |
|||||||||
|
Contact Resistance |
≤100mΩ（1A 24VDC） |
|||||||||
|
Operation Life |
Electrical |
1×10^5 ops |
||||||||
|
Mechanical |
1×10^7 ops |
|||||||||
|
Coil Parameter |
||||||||||
|
Rated coil power |
Sensitive type：540mW Standard type： 720mW |
|||||||||
|
Sensitive type |
||||||||||
|
Coil voltage VDC |
Pick up Voltage VDC |
Release voltage VDC |
Max voltage VDC |
|
Coil Resistance Ω（1±10％） |
Coil power consumption W |
||||
|
5 |
75% |
10% |
130% |
108 |
46 |
0.54 |
||||
|
6 |
88 |
68 |
0.54 |
|||||||
|
9 |
60 |
150 |
0.54 |
|||||||
|
12 |
44 |
268 |
0.54 |
|||||||
|
24 |
22 |
1068 |
0.54 |
|||||||
|
36 |
15 |
2400 |
0.54 |
|||||||
|
48 |
12 |
4268 |
0.54 |
|||||||
|
Coil Parameter |
||||||
|
Standard type |
||||||
|
Coil voltage |
|
Release voltage VDC |
Max voltage VDC |
Nominal Current |
Coil Resistance Ω（1±10％） |
Coil power consumptio n W |
|
5 |
75% |
10% |
130% |
143 |
35 |
0.72 |
|
6 |
120 |
50 |
0.72 |
|||
|
9 |
78 |
115 |
0.72 |
|||
|
12 |
60 |
200 |
0.72 |
|||
|
24 |
30 |
800 |
0.72 |
|||
|
36 |
20 |
1800 |
0.72 |
|||
|
48 |
15 |
3200 |
0.72 |
|||
|
Operation condition |
|||
|
Insulation Resistance |
1000MΩ |
||
|
Between Contacts |
1000VAC |
||
|
Between Contacts and Coil |
5000 VAC |
||
|
ction time (rated voltage) |
≦15ms |
||
|
elease time (rated voltage) |
≦5ms |
||
|
Shock Resistance |
98m/s2 980m/s2 |
||
|
Vibration Resistance |
10Hz~55Hz 1.5mm Double amplitude 1.5mm |
||
|
Terminals Strength |
6N |
||
|
Solderability |
280±10℃ |
2±1s℃ |
|
|
Ambient Temperature |
‐40~85℃ |
||
|
Relative Humidity |
5%~85% RH |
||
|
Mass |
13.0g |
||
